HAAS - VF-4SSCZ-MIL-HAA-2018-00001

Additional equipment

• linear rolling prestressed axle guide
• 15" LCD color monitor
• electronic micro scroll wheel
• module for quick detection of power failure
• 2 hand guns for air and liquid cleaning
• hanging tool shelf and notebook holder
• feet for setting up the machine
• WIP-S Renishaw probes
• 32GB extended memory
• TSC ready

Machine Benefits

Qualitative Machine Benefits

• Hours: run time: 9309h, feed cutting time: 2113h > excellent condition!
• Cnc control system haas in destination, compatible with fanuc
• Solid cast iron construction
• Temperature stabilization of the spindle , direct threading
• Lighting of the working area of the machine
• Ce version of the machine
• High speed machining

Technical Machine Benefits

• 3-axis version
• Working tracks x,y. Z = 1,270 x 508 x 635 mm
• Dimensions of the work table 1321 x 457 mm
• Number/dimension/spacing t-slot = 5 / 16mm / 80 mm
• Distance of the entire drive / surface of the table = 107-742 mm
• Iso40 / din69871/a drive type
• Max. Drive speed 12,000 rpm // max. Output 22. 4 kw, inline direkt drive drive // max. Spindle torque 122 nm
• 208 liter coolant tank with pump // cooling block with adjustable nozzles around the fan
• Electric connected 3x400v/50hz, 28kva
• Central automatic grease lubrication (spindle oil) // operating memory 1 gb // usb and ethernet communication interfaces
