This Mitsubishi Electric SG12M die-sinking EDM machine was manufactured in 2020. It features a robust 3750 kg weight, with a maximum workpiece weight capacity of 1000 kg. The machine includes a dielectric fluid chiller unit and a dual paper filter system, ensuring optimal operational conditions. The working tank has an automatic elevation system and hinji open-door for ease of use. If you are looking to get high-quality die-sinking capabilities, consider the Mitsubishi Electric SG12M machine we have for sale. Contact us for more information.
Resumen
- marca: Mitsubishi Electric
- año: 2020
- MODELO: SG12R
- tipo de aplicación: EDM
- Ubicación: Lituania
- tipo de máquina: Máquina de electroerosión por penetración
Información técnica - Mitsubishi Electric SG12R
Dimensiones
- Profundidad de la máquina: 1920 mm
- Altura de la máquina: 2420 mm
- Peso de la máquina: 3750 kg
Recorrido
- Recorrido eje X: 400 mm
- Recorrido eje Y: 300 mm
- Recorrido eje Z: 300 mm
Información adicional
Machine Benefits
Technical Machine Benefits
- Distance between table and electrode mounting surface: 200-500 mm / 300-600 mm
- Max. Electrode weight: 50 kg
- Working tank method: automatic elevation system / hinji open-door
- Working tank inner dimensions (w x d x h): 950 x 700 x 450 mm / 1050 x 700 x 450 mm
- Fluid level adjustment range (from top of table): 60-400 mm / 210-400 mm
- Max. Workpiece dimensions (w x d x h): 900 x 650 x 350 mm
- Table dimensions (w x d): 700 x 500 mm
- Distance between floor and top of table: 900 mm
Extra Information
Media Dielectric Fluid Reservoir Tank Capacity: 360 liters / 550 liters Initial Dielectric Fluid Supply Amount: 470 liters / 590 liters Filtering System: Paper filter x 2 Dielectric Fluid Chiller Unit: Included
*Pueden existir diferencias entre los datos mostrados y los reales, esto debe ser confirmado por el representante de ventas.
