WOODVER - UPK-1DE-SAW-WOO-2022-00001

• Max log diameter: 1000 mm

• Log length range: 2.0–6.5 m

• Saw diameter: 550 mm

• Saw rotational speed: 1500 (3000) rpm

• Main motor power: 2 x 18.5 kW

• Productivity: 12–20 m³/shift

Included features:

• Automatic carriage feed with adjustable travel speed

• Digital ammeter integrated in the control panel

• Three-part frame with two guides for precise geometry

• Remote control with CNC system

• Three-stage soft start system

• Laser pointer for cutting lines

• Digital cameras with 18.5" display integrated in the remote control

• Four hydraulic side clamps and four end clamps

• Hydraulic log tilting device that also centers the bar on the frame

Additional equipment

• Scraper conveyor
